Kevlar/Organic faced MDL Clutch Set 11″ long pattern 3-3/8″ Diaphragm pressure plate
Includes:
Kevlar on the pressure plate side /Organic facing on the flywheel side
10 spline 1-1/16″ disk
Mechanical T/O bearing
FH pilot bearing (Trucks require an MD-406-16515 T/O-bearing)
Clutch alignment tool
1-year warranty!
ALL our clutch disks are ‘ hand-built in-house ‘ so that we may control quality & tolerances. They are all checked & double-checked for accuracy before they go in the box for shipping.
Don’t see what you’re looking for, please call 208-453-9800
Additional information
Weight
400 oz
Dimensions
14 × 14 × 5 in
DETAILS
CLUTCH INFO:
Clutch Use
Street, Autocross, Road racing
Clutch Disk Quantity
Single
Input Spline Count
10
Input Shaft Diameter
1-1/16″
Torque Handling Capacity
600 lb./ft.
Disc Diameter
11″
Facing Material Press / F/W
Kevlar / Organic
Disc Style
Outer limit
Hub Style
Sprung
Pressure Plate Style
Diaphragm
Throw -out Bearing included
YES
Throw-out Bearing Style
Mechanical
Alignment Tool Included
YES
Pilot Bushing/Bearing Included
YES
Pilot Bushing/Bearing Material
Steel needle bearing
Pressure Plate Bolts Required
MDL Clutch Features:
* New hand-assembled & tested pressure plate, built to exceed the OEM specs * OEM-style clutch disc * New release bearing * Pilot bearing/bushing * Alignment tool for a perfect clutch installation
