Key Features
- 4.0" O.D. x .125" wall 6061-T6 aluminum tubing -- superior strength-to-weight ratio over factory steel
- 31-spline Sonnax billet steel slip yoke for precision fit and durability
- 113mm manual pinion flange for direct OEM differential compatibility
- 1350 U-joint size for heavy-duty torque transfer
- Professional high-speed balancing for vibration-free operation at all RPMs
- Custom-built to your exact measurements for perfect fitment
- Direct fit for 2005-2014 Mustang GT and GT500 with T56 Magnum XL transmission
- Made in the USA with lifetime technical support
Description
Factory steel driveshafts add unnecessary rotating mass that your engine has to accelerate with every stab of the throttle. That extra weight is magnified during rotation, robbing throttle response and slowing your S197 Mustang down. This custom aluminum driveshaft eliminates that dead weight while delivering the strength and precision your Magnum XL swap demands.
Built from 4.0" O.D. 6061-T6 aluminum tubing with .125" wall thickness, this driveshaft offers a superior strength-to-weight ratio compared to factory steel units. The larger diameter and thicker wall provide rigidity under high torque loads while substantially reducing rotating mass. Every shaft is professionally balanced at high speed to eliminate vibration from idle through redline.
The Sonnax billet steel slip yoke features 31 splines to match the T56 Magnum XL's output shaft, delivering precision engagement and exceptional durability. The 113mm manual pinion flange bolts directly to your Mustang's differential, and the 1350-series U-joint compatibility handles serious torque. Note: Pinion yoke may need to be updated to 1350 U-joint depending on your differential configuration.
Because every swap is different, MDL builds each driveshaft to your exact measurements. Simply complete and submit the Driveshaft Build Sheet to info@moderndriveline.com with your finished vehicle dimensions, and we'll build a shaft that fits perfectly. Made in the USA with lifetime technical support.
Kit Includes
- 4.0" O.D. x .125" wall 6061-T6 aluminum driveshaft tube
- 31-spline Sonnax billet steel slip yoke
- 113mm manual pinion flange
- Flange mounting bolts
- Professional high-speed balancing
- Lifetime technical support
