Key Features
- 3.5" OD aluminum tube with .125" wall thickness for optimal strength-to-weight ratio
- 31-spline Sonnax 1350 series forged steel slip yoke for maximum durability
- 113mm manual pinion flange for direct bolt-up to the differential
- 1350 series universal joints with 1.188" bearing cap diameter and 3.625" span
- Lightweight aluminum construction significantly reduces rotating mass vs. steel
- Custom-built to your vehicle's exact measurements for proper fit and optimal driveline angles
- Professionally balanced before shipping
- Made in the USA
Description
The OEM steel driveshaft in your '05-'14 Mustang GT wasn't designed for the 700 lb-ft torque capacity of the TREMEC T56 Magnum XL - and it's adding unnecessary rotating mass to your drivetrain. This custom aluminum driveshaft solves both problems with a lightweight, professionally balanced solution that matches the performance potential of your transmission upgrade.
Built with 3.5" outside diameter aluminum tubing and .125" wall thickness, this driveshaft delivers the strength needed for high-performance applications while significantly reducing weight compared to steel. The 31-spline Sonnax forged steel yoke connects to your T56 Magnum XL's slip yoke output, while the 113mm manual pinion flange bolts directly to the differential. The 1350 series universal joints - with 1.188" bearing caps and 3.625" span - are a substantial upgrade over smaller 1310 series joints found in many street applications.
Every driveshaft is custom-built to your vehicle's exact measurements. The T56 Magnum XL's extended-length tail section eliminates the semi-remote shifter found in factory transmissions, which changes the driveshaft length requirements compared to stock. We use your completed build sheet measurements to ensure proper fit, critical angles, and optimal performance. Simply download the driveshaft build sheet, take your measurements with the vehicle at ride height, and submit to info@moderndriveline.com.
Compatible with 2005-2014 Mustang GT and GT500 models equipped with 4.6L or 5.0L engines and the T56 Magnum XL transmission. This is a custom-manufactured component - allow additional time for build and balancing. Made in the USA with lifetime tech support.
Kit Includes
- Custom aluminum driveshaft with 3.5" OD x .125" wall tube
- 31-spline Sonnax 1350 series forged steel slip yoke
- 113mm manual pinion flange
- 1350 series universal joints
- Flange bolts
- Professional balancing
- Lifetime tech support
