Key Features
- Application-specific for 1979-1993 Fox Body Mustang with T5 transmission and 28-spline output shaft
- Designed for Ford 8.8 rear differential with small flange pinion configuration
- 3.0-inch steel tube construction for strength and durability
- 1310 series universal joints matched to small flange bolt pattern
- Forged steel slip yoke for reliable power transfer under load
- Professionally balanced and painted black
- Custom-built to your exact vehicle measurements
- Made in the USA
Description
When you're building a Fox Body, every component in your drivetrain matters -- including the shaft that connects your T5 to the rear axle. Factory driveshafts weren't designed for upgraded suspensions, lowered ride heights, or any transmission swap work you've done along the way. This custom steel driveshaft is engineered specifically for 1979-1993 Mustangs running a T5 five-speed with the Ford 28-spline output shaft and an 8.8 rear differential using the small flange pinion setup.
The 3.0-inch steel tube provides the rigidity needed for street and spirited driving, while the forged steel slip yoke mates precisely to your T5's 28-spline output. The 1310 series universal joints are matched to the small bolt pattern found on most V8 Mustang 8.8 rear ends. Every driveshaft is professionally balanced and painted black for corrosion resistance and a clean underbody appearance.
Because no two builds are identical -- especially after suspension modifications, transmission swaps, or rear end changes -- this driveshaft is custom-fabricated to your exact measurements. You'll complete our driveshaft build sheet with dimensions taken from your finished vehicle, ensuring proper driveline geometry with no vibration or binding issues.
Compatible with 1979-1993 Ford Mustang equipped with T5 transmission (28-spline output) and Ford 8.8 rear end with small flange pinion. Made in the USA with lifetime technical support.
Kit Includes
- Custom steel driveshaft assembly, 3.0-inch tube diameter
- Forged steel slip yoke, 28-spline
- 1310 series universal joints
- Ford 8.8 small flange yoke
- Professional high-speed balancing
- Black paint finish
- Lifetime technical support
How to Order
This driveshaft requires measurements taken from your completed vehicle. Download the driveshaft build sheet from our website and submit the completed form to info@moderndriveline.com. We use your measurements to fabricate a driveshaft with proper length and driveline angles for your specific build. Please note: yokes for these driveshafts may be on backorder -- contact us regarding current availability before ordering.
