1994-2004 SN-95 Mustang Hydraulic Clutch Master KitLight Foot Series - Type 2 (.700" bore x 1.4" stroke)

** This kit is used with forward-mounted PCV Valve in DOHC valve-cover.

**NOTE: In some cases, his kit may not clear the 32V motor valve cover, please call for your application.

If your PCV valve is rear mounted on your DOHC you must use the MD-910-0092-P

SEMA 2019 Award winner for the Best New Engineered Productfor our 1994-2004 Mustang Hydraulic Clutch Conversion.

Features:

The conversion that uses stock pedal

Pedal linkage to convert pull to push

No-drill, Bolt-in application

Available in three bore sizes to match slave cylinder volume

Integral reservoir

Works with SOHC / DOHC / Modular V8

One man bleeder kit included

This kit converts the factory clutch cable to hydraulic using the stock pedal assembly and clutch cable mounting location.The kit requires no drilling and can be installed with basic hand tools.This kit includes:

the master cylinder which features an integral reservoir

mounting bracket

pedal linkage

all mounting hardware needed. The Master cylinder clears both SOHC & DOHC Mod Motors.
Revolutionary Linkage Design

The LF Series Hydraulic Clutch Master is a revolutionary design for retrofitting hydraulics into the classic cars Modern Driveline solved these issues with innovative pedal linkage that matches pedal travel with a long stroke master cylinder for a reduced clutch pedal load.The linkage allows for great design flexibility and greatly improved driver's experience.We offer the master cylinders in three different bore sizes to match the slave cylinder volume requirements.In most cases, our .700" bore with 1.4" stroke is the perfect match for most slave cylinders on the market and all our LF series slaves, Tilton 6000 Series internal bearings. Click here to learn more about the Tilton 6000 Slave Throw-out bearing Please contact us if you have any special requirements.

The long-stroke, small bore master cylinder provides minimized loading of the firewall and pedal effort.

A firewall plate with mechanical linkage greatly reduces firewall load and pedal effort while providing design flexibility to use the stock clutch rod hole.

The mechanical linkage design also allows the full stroke of the pedal to maximize clutch modulation while keeping the cylinder perpendicular to the firewall and providing mechanical advantage and reducing the pedal pressure required to operate the clutch.
Complete solutions of master and slave need to be optimized with matching fluid volume.For this reason, we offer kits specifically matched to our slaves or to existing slaves on the market.
See our recommended slave cylinders below.
Our Type 2 .700" Bore x 1.4" stroke master coupled with our complete line of slave cylinders for T5, T45, 3650, and Magnum 6-speed for a complete engineered solution the first time.
This upgrade makes driving fun again with minimal pedal effort and exact actuation every time.Type 3 .750" bore x 1.4" stroke also available

ALL of our hydraulic master kits are ' hand-assembled in-house 'so that we may control quality & precision.They are all checked & double checked for fit & finish before they go in the box for shipping.

Click here for helpful guides & information on our HOW TO page

Don't see what you're looking for, please call 208-453-9800

MDL LF Series 94-04 SN95 Mustang Hydraulic Clutch Master Kit .700" Bore/ integral Reservoir
