Key Features
- Drawn Over Mandrel (DOM) seamless steel tubing - superior torsional strength and concentricity vs. standard electric-welded tube
- Billet steel slip yoke with 31-spline configuration for maximum torque engagement
- 1350 series U-joints rated for 2,200 lb-ft yield torque - approximately 37.5% stronger than 1310 series
- 3.0" tube diameter for optimal balance of weight and strength in street/strip applications
- Custom length capability up to 57" center-to-center measurement
- High-speed balanced assembly for vibration-free operation
- Black painted finish for corrosion resistance
- Made in the USA
Description
When your transmission swap or performance build demands a driveshaft that can handle serious power without introducing vibration, this custom steel driveshaft delivers the solution. Standard electric-welded tubing has an internal weld seam that creates balance issues and stress concentration points under high torque loads. DOM (Drawn Over Mandrel) tubing eliminates these problems - the manufacturing process removes the flash weld and cold-draws the tube over a precision mandrel, resulting in better dimensional tolerances, improved surface finish, and superior concentricity that makes balancing easier and more accurate.
The billet steel slip yoke provides material integrity that stamped alternatives simply can't match, while the 31-spline configuration delivers the engagement area needed for serious torque transfer. The 1350 series U-joints represent a significant strength upgrade over factory 1310 joints - they're designed for high-torque performance applications producing 600 lb-ft and above, making them essential for any modified drivetrain. The 3.0" tube diameter strikes the optimal balance between rotational mass and torsional strength for most street and strip builds.
Every driveshaft is professionally high-speed balanced to eliminate the vibrations that destroy drivetrain components and ruin the driving experience. The custom length capability up to 57" center-to-center accommodates non-standard installations, transmission swaps, and chassis modifications where off-the-shelf solutions won't fit. This isn't a universal part - it's built specifically for your measurements using the driveshaft build sheet.
Requires completion of the driveshaft build sheet with your specific measurements once your transmission is installed. Submit the completed form to info@moderndriveline.com to begin production. Made in the USA using professional-grade construction and cutting-edge manufacturing processes.
How to Order
This driveshaft is built to your specifications once measurements are taken from your completed vehicle. After your transmission is installed, complete the driveshaft build sheet with your center-to-center measurement and submit it to info@moderndriveline.com. Questions? Call 208-453-9800.
Kit Includes
- Custom-length steel DOM tube (3.0" diameter)
- Billet steel slip yoke (31-spline)
- 1350 series U-joints
- Professional high-speed balancing
- Black paint finish
- Lifetime technical support
