Key Features
- Drawn Over Mandrel (DOM) 3" seamless steel tube - 15% stronger than OEM welded construction
- 31-spline forged steel slip yoke for maximum durability under high torque loads
- 1310 series U-joints (1.062" cap diameter, 3.219" cross width) - proven street/performance reliability
- 3.5" bolt circle companion flange for differential connection
- Custom lengths up to 52" center-to-center measurement
- High-speed balanced and painted black for corrosion resistance
- Made in the USA
Description
When a transmission swap, rear-end upgrade, or custom build changes your driveline geometry, you need a custom-length driveshaft that can handle serious torque without introducing vibration. This MDL steel driveshaft delivers the strength and precision your build demands, replacing weak OEM units or filling the gap when stock lengths simply won't work.
The engineering starts with Drawn Over Mandrel (DOM) seamless 3" steel tubing - a manufacturing process that produces superior concentricity and uniform wall thickness compared to welded alternatives. DOM tubing is 15% stronger than OEM construction, eliminating the balance issues and weak points that plague cheaper driveshafts. The forged steel 31-spline slip yoke connects to any transmission with a 31-spline output shaft, providing maximum durability where it matters most.
Power transfer relies on 1310 series U-joints with 1.062" bearing caps and 3.219" cross width - a proven configuration for street and performance applications. The 3.5" bolt circle companion flange accommodates most rear differentials, while custom lengths up to 52" center-to-center handle virtually any application. Every shaft receives high-speed balancing to eliminate vibration and comes painted black for corrosion protection.
Built using the latest cutting-edge technologies and highest manufacturing standards, this driveshaft works equally well for restoration projects needing a replacement part or custom builds demanding high-level performance. Made in the USA.
How to Order
This driveshaft requires measurements from your vehicle after the transmission has been installed. Download and complete the Driveshaft Build Sheet, then submit the completed form to info@moderndriveline.com. Questions? Call 208-453-9800.
Kit Includes
- DOM 3" seamless steel driveshaft tube, custom length (up to 52" c-to-c)
- 31-spline forged steel slip yoke
- 3.5" bolt circle companion flange
- 1310 series U-joints (2)
- High-speed balancing
- Black painted finish
