Key Features
- 31-spline forged slip yoke matches T56 Magnum output shaft exactly
- Ford 8.8 large flange companion flange (4.25" bolt circle, 2" center pilot)
- 3.5" steel tube for strength and rigidity
- 1310 series U-joints
- High-speed balanced to eliminate vibration
- Black painted finish
- Custom-built to your vehicle measurements
- Made in the USA
Description
Swapping a TREMEC T56 Magnum into a Fox Body Mustang means your factory driveshaft is now the wrong length, wrong spline count, and possibly wrong rear flange pattern. This custom steel driveshaft solves all three problems in one professionally built assembly designed specifically for 1979-1993 Mustangs running T56 Magnum transmissions with Ford 8.8 large flange rear ends.
The 31-spline forged slip yoke slides directly onto the T56 Magnum's output shaft with zero adapters required. At the rear, the companion flange bolts to Ford 8.8 differentials equipped with the large 4.25" bolt circle pinion flange - the same pattern found on full-size Ford cars, light trucks, and Cobra Mustangs. The 3.5" steel tube provides the rigidity needed for clean power transfer, and every shaft is high-speed balanced to eliminate vibration that can plague custom driveshafts.
Because every T56 Magnum swap is different - tunnel clearances vary, transmission mount locations differ, and rear axle setups change - this driveshaft is built to order using your specific measurements. Submit the completed driveshaft build sheet to info@moderndriveline.com with your finished vehicle measurements, and MDL will build a shaft that fits your exact application.
Professionally built in the USA with high-speed balancing and a black painted finish. Perfect for street-driven performance builds where smooth operation and reliability matter as much as power handling capability.
How to Order
This driveshaft is built to your vehicle's measurements once your project is complete. Download and fill out the Steel or Aluminum Driveshaft Build Sheet (select "Steel" when completing the form), then submit to info@moderndriveline.com to start your build.
Kit Includes
- Custom-length 3.5" steel driveshaft tube, black painted
- 31-spline forged steel slip yoke
- Ford 8.8 large flange companion flange
- 1310 series U-joints
- High-speed balancing
