    Purchase MDL Modified Tremec Ford TKX 5-Speed, with 1.000" - 1.500" Fwd Offset

    Tremec

    MDL Modified Tremec Ford TKX 5-Speed, with 1.000" - 1.500" Fwd Offset

    SKU: MD-501-18086-FS21-2010F

    No reviews yet. Write a review!
    $4,100.00 Original Price
    Price excludes tax


    Join Waitlist

    Sign up with your email to be notified when this is back in stock!



    MDL Modified Tremec Ford TKX 5-Speed
    with 1.000in. - 1.500in. Forward Offset Shift Stub

    Close ratio / short throw TKX to bring your shifter lever up where you need it.
    The narrow shift body will clear the shifter hole without cutting the floor.
    Taking all the worry and hassle out of shifter placement.

    Featuring:

    • Front mounted Shifter with a 1.0in. / 1.50in.  forward offset Shift Stub
    • Gear Ratios 2.87, 1.89, 1.28, 1, .72od
    • 10-spline input, 31-spline output
    • Mechanical and Analog Electric speedo drive
    • Torque rated for 600ft/lbs.
    • Multi-cone synchronizers have an 8,000 RPM shift capability for a smooth, fast shift.
    • Slimline, end-loading case

    Not available through Tremec, this is an MDL Exclusive

    Specifications

    Bellhousing Bolt Pattern
    Ford Wide Pattern
    Gear Ratio 1st Gear
    3.27
    Gear Ratio 2nd Gear
    1.98
    Gear Ratio 3rd Gear
    1.34
    Gear Ratio 4th Gear
    1.0
    Gear Ratio 5th Gear
    0.72
    Input spline count
    10.0
    Oil Type Requirements
    ATF Dextron III
    Output spline count
    31.0
    Shift Positions
    Front Position
    Transmission
    TKX
