Modified TREMEC T5Z 5-Speed | Aston Martin | 2.95 First, 0.73 OD | Stock Shifter
Key Features
- 330 ft-lb torque capacity - handles up to 450 hp on street tires
- 2.95 first gear ratio for strong launch performance
- 0.73 overdrive drops cruise RPM for improved fuel economy and reduced engine wear
- World Class internals with carbon fiber synchronizer rings on gears 1-4
- Flat-machined mounting pad 4" wide, centered on transmission centerline for Aston Martin chassis alignment
- Custom 0.749" pilot tip, 7.625" length input shaft machined specifically for Aston Martin crankshaft pilot bore
- 10-spline input shaft (1-1/16" diameter) and 28-spline output shaft
- Steel front bearing retainer with Cobra-style pocket bearing
- Tapered carrier bearings and main needle bearings throughout
- 7-tooth speedometer drive gear (6 and 8-tooth available)
- Just 75 lbs dry - TREMEC's most compact transmission
- Direct replacement for 1983-1993 V8 Mustangs
- Optional 0.63 overdrive ratio available
- Shifter Stub Location: straight up on center line, 19.50” back from the bellhousing face
Description
Classic Aston Martin owners face a unique challenge when upgrading to a modern 5-speed overdrive: virtually nothing fits without extensive custom fabrication. This MDL-modified T5Z solves that problem with application-specific machining designed around Aston Martin dimensional requirements. The custom input shaft features a 0.749" pilot tip sized precisely for Aston Martin crankshaft pilot bores, while the flat-machined mounting pad -- 4" wide and centered on the transmission centerline -- ensures proper alignment with factory Aston Martin mounting configurations.
The smallest and lightest transmission in the TREMEC lineup at just 75 lbs dry, the T5Z fits where larger transmissions simply cannot. Don't let the compact size mislead you -- this transmission safely handles 330 ft-lb of torque and is suitable for 450 hp streetcars running DOT-approved tires. The World Class internals featuring tapered carrier bearings, main needle bearings, and carbon fiber synchronizer rings on 1st through 4th gears deliver smooth, precise shifts with excellent long-term durability.
The 2.95 first gear provides strong acceleration off the line, while the 0.73 overdrive drops highway RPMs significantly -- improving fuel economy, reducing engine temperatures, lowering drivetrain wear, and delivering a quieter, more relaxed cruising experience. For Aston Martin restorations where originality takes a back seat to driveability, this MDL-modified T5Z delivers modern transmission performance in a package engineered to fit. Requires 2.75 quarts of ATF Dexron III.
Call MDL at 208-453-9800 to discuss your specific Aston Martin application and verify fitment details for your particular chassis.
Kit Includes
- TREMEC Super Duty T5 transmission assembly (TREMEC part number 1352-251) with 2.95, 1.94, 1.34, 1.00, 0.73 gear ratios
- Custom 10-spline input shaft with 0.749" pilot tip
- 28-spline output shaft
- Steel front bearing retainer
- Cobra-style pocket bearing
- Carbon fiber synchronizer rings (1st through 4th gears)
- 7-tooth speedometer drive gear (6 or 8-tooth available separately)
- Flat-machined mounting pad (4" wide, centered on centerline)
- Built-in reverse light switch (left side)
- Built-in cruise control safety switch (right side)
- Mechanical speedometer drive gear (7-tooth Ford pattern)
- Fill and drain plugs
- Installation instructions
- MDL extended warranty: manufacturer warranty plus 1 additional year with 1-year grace period
- Lifetime technical support from Modern Driveline
