Key Features
- 9-inch clutch disk with 1-1/16-inch, 10-spline hub for Aston Martin applications
- Organic/organic friction facings for smooth engagement and street durability
- Diaphragm pressure plate delivers consistent clamping force
- Sprung hub design dampens drivetrain vibration and smooths power transfer
- 200 lb-ft torque capacity handles stock and mildly modified engines
- Mechanical release design for cable or fork-actuated systems
- Hand-assembled in-house with precision tolerances and double-checked quality control
- Complete kit includes pressure plate, clutch disk, throw-out bearing, pilot bushing, and alignment tool
- 1-year free-from-defect warranty
- Made in the USA
Description
Sourcing a reliable clutch for vintage Aston Martin applications can be a frustrating exercise in hunting obsolete parts or settling for questionable aftermarket offerings. The Superior Series 9-inch clutch assembly solves that problem with a purpose-built disk engineered specifically for the 1-1/16-inch, 10-spline input shaft found in select Aston Martin drivetrains.
Every Superior clutch disk is hand-assembled at MDL's facility in Idaho, where critical tolerances--spline engagement, hub concentricity, and friction material adhesion--are double-checked before the assembly leaves the shop. The organic friction facings on both sides deliver the progressive engagement characteristics that make street driving enjoyable, without the grabbiness or chatter of aggressive racing compounds.
The diaphragm pressure plate maintains consistent clamping force throughout its service life, eliminating the hot spots and uneven wear that plague inferior designs. The sprung hub absorbs torsional shock from the engine and smooths power delivery through the drivetrain--critical for preserving gearbox synchros and providing refined pedal feel. At 200 lb-ft torque capacity, this assembly handles stock and moderately upgraded powerplants without slippage.
The kit arrives ready to install with everything you need: pressure plate, clutch disk, throw-out bearing, pilot bushing, and an alignment tool to ensure proper indexing during assembly. Backed by MDL's 1-year free-from-defect warranty and lifetime technical support. Made in the USA.
Kit Includes
- Diaphragm pressure plate
- 9-inch organic/organic clutch disk (1-1/16-inch, 10-spline hub, sprung center)
- Throw-out bearing
- Pilot bushing
- Clutch alignment tool
- Installation and break-in instructions
- Lifetime technical support
