Key Features
- 350 ft-lb torque capacity for performance street applications
- Kevlar/organic friction facings balance durability with smooth engagement
- Diaphragm pressure plate delivers consistent clamping force
- 26-spline x 1-1/16" hub for GM TKO and TKX transmission conversions
- 10" long pattern bolt configuration fits Ford Flathead 59A and 8BA applications
- Sprung hub design absorbs driveline shock and reduces gear rattle
- Includes Ford Flathead pilot bearing and 0.590" alignment tool
- Hand-built clutch disk with in-house quality control
- Made in the USA with 1-year warranty
Description
Converting your Ford Flathead V8 to a modern TREMEC five-speed requires a clutch purpose-built for the swap. Due to the design of modern diaphragm clutches, only 10" long pattern clutches fit the 59A engine and 8BA stamped or cast bell ring design. This MDL Superior clutch kit delivers the correct bolt pattern with 26-spline compatibility for TKO and TKX transmissions running the GM-style input shaft.
The Kevlar/organic friction material strikes an ideal balance between street manners and performance capability. Kevlar fibers provide exceptional heat resistance and durability under repeated engagement, while the organic compound ensures smooth pedal feel and extended service life. The diaphragm pressure plate maintains consistent clamping force across the entire friction surface, eliminating the hot spots and uneven wear common with older three-finger designs.
Every Superior clutch disk is hand-built in MDL's Caldwell, Idaho facility, where technicians control critical tolerances that mass-produced units cannot match. The sprung hub absorbs driveline shock loads that would otherwise stress transmission components, and each assembly is checked and double-checked for accuracy before shipping. The included Ford Flathead pilot bearing and precision 0.590" alignment tool ensure proper installation.
Designed specifically for Ford Flathead V8 engines converting to GM TKO or TKX transmissions with 26-spline input shafts. Note: Throwout bearing is not included with this kit. Engineered and manufactured in the USA, backed by MDL's 1-year warranty and lifetime technical support.
Kit Includes
- 10" long pattern diaphragm pressure plate
- Kevlar/organic facing clutch disk, 26-spline x 1-1/16" hub, sprung center
- Ford Flathead pilot bearing
- 0.590" clutch alignment tool
- Installation and break-in instructions
- 1-year warranty coverage
- Lifetime technical support
