Key Features
- 11-inch diameter clutch optimized for LS-to-LS T56 Magnum applications
- Steel-backed organic facings deliver 350 ft-lb torque capacity for performance street builds
- 10-spline x 1-1/16-inch hub compatible with Ford 3/8-inch input shafts
- LS bolt pattern pressure plate for direct fitment to LS flywheels
- Diaphragm-style pressure plate for consistent pedal feel and smooth engagement
- Sprung hub design absorbs drivetrain shock and reduces gear rattle
- Hand-assembled and double-checked in MDL's Idaho facility before shipping
- Performance Proven tested on and off track
- Made in the USA with 1-year free-from-defect warranty
Description
The MDL Superior Series 11-inch clutch kit solves the fitment challenge builders face when pairing LS engines with Ford-style input shaft transmissions. This hybrid configuration pairs an LS bolt pattern pressure plate with a Ford-compatible 10-spline x 1-1/16-inch hub, enabling you to run the proven LS flywheel pattern while connecting to Ford-style 3/8-inch input shafts found in select T56 Magnum configurations.
Steel-backed organic facings strike the optimal balance between street drivability and performance durability. The steel backing plates prevent facing separation under load while organic friction compounds deliver smooth, progressive engagement without the harshness or chatter of ceramic materials. Rated at 350 ft-lb of torque capacity, this clutch handles modified LS engines while maintaining reasonable pedal effort and excellent street manners.
Every Superior Series clutch is hand-assembled at MDL's facility in Caldwell, Idaho. Each pressure plate and disc combination is checked and double-checked for proper alignment, facing adhesion, and smooth operation before packaging. This attention to detail eliminates the fitment issues and quality inconsistencies common with mass-produced alternatives. The Performance Proven designation means this clutch has survived rigorous racing challenges both on and off the track.
Designed for performance street applications, this kit delivers reliable engagement for daily-driven builds and weekend warriors alike. Compatible with hydraulic release systems and backed by MDL's lifetime technical support and 1-year free-from-defect warranty.
Kit Includes
- 11-inch diaphragm pressure plate with LS bolt pattern
- Single disc with steel-backed organic facings and sprung hub (10-spline x 1-1/16-inch)
- Pilot bearing
- Clutch alignment tool
- Pressure plate bolts
- Installation and break-in instructions
- Lifetime technical support
Note: Release bearing not included and must be sourced separately for your specific application.
