Key Features
- Hand-assembled in-house at MDL with double-checked quality control and 1-year free-from-defect warranty
- Severe-duty diaphragm pressure plate delivers increased clamp load with reasonable pedal effort
- Steel-backed organic facings provide smooth, progressive engagement and extended service life
- 10.5" diameter disc with 26-spline 1-1/8" hub configuration
- 11-5/8" equidistant bolt pattern pressure plate fits standard Mopar applications
- .670" ID pilot bushing and matching alignment tool included for proper installation
- Sprung hub disc absorbs driveline shock for smoother streetability
- Rated for 300 lb-ft torque capacity -- ideal for performance street applications
- Performance Proven -- tested in racing applications on and off track
Description
Give your Mopar the clutch upgrade it deserves with a precision-built severe-duty unit engineered for performance street driving. This single-disc clutch set pairs a heavy-duty diaphragm pressure plate with steel-backed organic facings -- a combination that delivers substantially increased clamp load over stock while maintaining the smooth, progressive engagement characteristics that make daily driving enjoyable. The steel backing adds structural rigidity to the friction material, reducing heat-related warping and extending service life under spirited use.
Every MDL Superior clutch is hand-assembled in-house to ensure quality and flawless operation before shipping. Each component is checked and double-checked for accuracy, delivering a ready-to-install premium piece right out of the box. The sprung hub disc absorbs driveline shock and chatter, while the diaphragm-style pressure plate provides consistent clamp force across the entire engagement range. Rated at 300 lb-ft torque capacity, this clutch set is purpose-built for performance street applications where reliability and drivability matter as much as holding power.
This clutch set features a 10.5" diameter disc with 26-spline 1-1/8" hub configuration and 11-5/8" equidistant bolt pattern pressure plate for standard Mopar applications. The included .670" ID pilot bushing and matching alignment tool ensure proper installation and concentricity. Designed for mechanical clutch actuation systems. Proudly crafted with care in the USA and backed by a 1-year free-from-defect warranty.
Kit Includes
- Severe-duty diaphragm pressure plate -- 11-5/8" equidistant bolt pattern
- 10.5" steel-backed organic clutch disc -- 26-spline 1-1/8" sprung hub
- .670" ID pilot bushing
- .670" OD pilot tip clutch alignment tool
- Installation and break-in instructions
- 1-year free-from-defect warranty
- Lifetime MDL tech support
Note: Throwout bearing not included with this kit.
