Quick Time Bellhousing RM-8055 Ford Y block to Ford T5 or 3550/TKO500-600
Features
Features
- Whatever engine or transmission you have hard-to-find and even one-of-a-kind applications are a reality with Quick Time
- Twice the strength of other steel bellhousings, with pinpoint dimensional accuracy and stability that obsoletes lesser models made from rolled or stamped steel
- The engine and transmission always stay in alignment through the entire rpm range, eliminating accelerated drivetrain wear caused by bellhousing flex
- Patent Pending on 16 points of Bellhousing Design & Process
- 100% built in the USA
- Design input from OEM, Engine Builders, Transmission Builders, Racers, and the Hobbyist
- Quick Time Bellhousings are the most accurate bellhousings available due to our unique manufacturing process
- Height = 6.925
- Trans. Bore = Universal 4.910/4.850
- Engine = Ford "Y" Block
- Trans. = Universal Ford TKO 500-600/TR 3550/T5 Mustang
- Clutch = 11"
- Flywheel = 164 tooth (Flywheel available @ Modern Driveline #MD-LBS-YBlock Phone #208-453-9800)
- Weight = 21#
- Has passed SFI testing
- Pivot ball, fork brackets, full engine plate, and grade 8 bolts included
- You will need to use our flywheel. (MD-LBS-Yblock) Steel billet 164 tooth with Y block bolt pattern. Flywheels are double drilled for 10.4 metric pattern as well as 11" Ford
- Starter is a 4.6L/5.4L (See PN MD-700-1008)
