Key Features
- Flat-face design with 47mm - 66mm (1.85" - 2.60") contact diameter for bent-finger and diaphragm clutches
- OD-spinning bearing that press-fits directly onto the hydraulic release bearing piston
- Compatible with Tilton 60-1100, 60-3100, 60-4100, 60-5100, 60-61xx, and 60-8100 series HRBs
- Works with all Tilton hydraulic release bearings except the 9000-Series
- Genuine Tilton replacement - the same long-life bearing used in factory HRB assemblies
- Direct-fit service component - no machining or modification required
Description
When your Tilton 6000 Series hydraulic release bearing develops roughness, increased resistance, or a notchy feel during rotation, this genuine replacement flat-face bearing restores smooth, consistent operation. Rather than replacing the entire HRB assembly, this service component lets you renew just the wear item - the bearing itself - while keeping your existing piston and hydraulic body in service.
The flat-face profile is specifically designed for pressure plates with flared or bent finger tips, providing proper contact geometry across the 47mm - 66mm contact diameter range. This makes it compatible with most 8.5" - 11" bent-finger and diaphragm-type clutches. The bearing features an OD-spinning design that press-fits onto your existing release bearing piston, eliminating the play and inconsistency that develops as bearings wear.
This is the same high-quality bearing Tilton installs in their factory HRB assemblies - not an aftermarket substitute. It fits a wide range of Tilton hydraulic release bearing part numbers including the 60-1100, 60-3100, 60-4100, 60-5100, 60-61xx, and 60-8100 series. The only exception is the 9000-Series, which uses a different bearing configuration.
Installation is straightforward: the old bearing presses off the piston, and the new bearing presses on. If your pedal feel has degraded or you notice any roughness when spinning the bearing race by hand, this replacement restores the smooth, consistent operation your hydraulic clutch system requires.
Kit Includes
- Tilton flat-face hydraulic throwout bearing (P/N 62-618)
