Tremec Magnum-F 6-Speed Transmission 2.97/.50-TUET17638


Category: SKU: MD-586-17638


6-Speed for 82-02 GM F-body Camaros & Firebirds wide ratio


Perfect for:
…..3rd GEN F-bodies
     LT1-powered 4th GEN F-bodies
     LS-swapped late models.
Sport compacts
……A80 Supras, FD RX-7s

The Magnum-F has a shifter location, which is nearly 3 inches further back than on the original Magnum.


Interface……………………………..GM LS T-56
Torque Capacity………………….700 lb-ft.
Gear Ratios………………………….2.97, 1.78, 1.30, 1, .74, .50
RPM Rating…………………………7800
Clutch Release…………………… Hydraulic
Speedometer……………………… Electronic, 17 Tooth
Input / Output Splines…………  26 / 31

Ratios…………………………………. Multiple, stock & altered
Weight……………………………….. 128 lbs.





Available through Modern DriveLine

The Magnum-F is the trans rendering junkyard crawls
and difficult custom builds a thing of the past!


Experience the MDL difference:

When you purchase a complete MDL Conversion Package you get

    • We extend the manufacturer’s warranty by an extra year… with a 1-year grace period.
    • We have the best in the industry customer service.
    •  life-time technical support.

Consider Your Old F-car T-56 Obsolete!


Designed to replace aging T-56 transmissions in LS1-powered fourth-generation GM F-bodies.
These transmissions are the strongest 6speed manuals ever built.
They can withstand up to 700 ft.-lbs. of torque, with gears featuring substantially increased face widths

The Magnum-F is the latest addition to TREMEC’s hard-hitting Magnum 6-speed series. Based on the TR-6060 used in numerous late-model factory performance machines, it combines brute strength with modern OEM refinement for the ultimate gear-rowing experience.
Built to surpass even the most heavily fortified T-56, it also eliminates the need for over-hyped ‘Stage 6’ or ‘Level X’ rebuilds; along with the concern that comes from rebuilding with inferior offshore parts.

1st: 2.97,    2nd:2.10,    3rd:1.46,    4th:1.00,    5th:0.74,    6th:.50

Internal CSC Mount
Torque rated 700+ft/lbs
17 tooth Analog Electric speedo
Shifter location: 29.4″ from back of block


T56 Magnum, Magnum XL & Magnum F cannot be ordered online, we ask that you please call us at:

One of our sales agents will be more than happy to process your order.

This item can only be shipped via ( LTL ) – Light Truck Load service UPS ground is not an option
due to the weight of the item, see below.

UPS LTL freight shipping cost to a commercial or nearest freight depot address only
within the lower 48 states.
( Shipment to a Residential Address is an additional $125 and can be billed after delivery )

What’s Inside:

Inside, this new transmission benefits from the same durable components found in many of today’s hardest-hitting OEM muscle & sports cars.
Over the T-56, the Magnum-F boasts increased face-width on all gears, a robust combination of double and triple cone synchronizers, enhanced webbing in the main case, provisions for a cooler circuit, and more!
TREMEC also took the opportunity to upgrade the shifter to an isolator-type unit, like that found on its Magnum XL.
This shifter reduces in-cabin noise and vibrations while at the same time providing the precise and communicative shift feel that all Magnums are known for.

Just like all TREMEC aftermarket transmissions, the Magnum-F is made from 100% brand-new OEM-quality content.

MEET THE MAGNUM  6-SPEED called the F:

Magnum F the long-awaited and highly-anticipated F-car-specific version of TREMEC’s popular Magnum 6-speed has finally arrived!
Designed to replace T-56 transmissions in 1998-2002 GM F-bodies, the new-F leverages TREMEC’s pervasive TR-6060/Magnum architecture in order to provide fourth-gen enthusiasts significantly improved performance and relief from a shrinking pool of quality T-56 replacement parts.


” Aimed first & foremost at ‘98-02 F-cars
The Magnum-F can also be used in third-gen and LT1-powered F-bodies with minimal modification.”

in addition to a host of sport compact applications that previously relied on the F-car T-56 for its ideal shifter location.

Available now through Modern DriveLine, the Magnum-F is the trans rendering junkyard crawls and custom builds a thing of the past!


From great beginnings:

Born in the vacuum created by the release of the original T-56 Magnum (now known simply as ‘Magnum’) back in 2009.
The Magnum-F fills a longstanding void in the overall Magnum line with regard to shifter locations; addressing not only LS1-powered ‘98-02 F-bodies.
As well as several other applications that utilize a similar shifter position.
These include third-generation F-bodies, LT1-powered fourth-gens, LS-swapped late models of all varieties, and sport compact applications such as A80 Supras, FD RX-7s, and more!


Where the original Magnum shifter locations may prove too far forward, and the extended length Magnum XL’s too far back.
Tremec’s Magnum-F’s in-between position often proves to be just right.

  • MD-586-16362 (TUET16362) with  2.66 first Gear
  • MD-586-16363 (TUET16363) with  2.97 first Gear


TREMEC Elite logo

Modern DriveLine

Your Elite Distributor is proud to carry Tremec’s Magnum-F
In stock & ready to ship



Additional information

Weight 2500 oz
Dimensions 46.5 × 22 × 20 in



Dimension A:  6.5″ / 16.1 cm
Dimension B:  23.9″ / 60.7 cm
Dimension C:  13.0″ / 33.2 cm
Dimension D:   12.25″ / 31.2 cm
Dimension E:   21.06″ / 54.0 cm
Dimension F:   32.46″ / 82.5 cm
Dimension G:   3.37″ / 85.5 cm

  1. 4th-Gen ‘F-body’ extension housing
  2. 4th-Gen ‘F-body’ shifter location
  3. Reverse inhibitor solenoid
  4. Electronic speedometer output
  5. Fluid fill & drain ports
  6. Common ‘T-56’ style bolt pattern, works with factory LS1 & LS2 Bellhousings
  7. Mounting pad for OEM style hydraulic slave or aftermarket guide tube


Model Number TUET16362 TUET* (TBD) TUET 17638 TUET16363
Application1 GM GM GM GM
Engine2 LS LS LS LS
Torque Capacity3 700 700 700 700
RPM Rating3 7800 7800 7800 7800
Includes Clutch Housing No No No No
Clutch Release Type4 Hydraulic Hydraulic Hydraulic Hydraulic
Speedometer Type5 Electronic Electronic Electronic Electronic
Speedometer Pulses5 17T 17T 17T 17T
Input Splines5 26 26 26 26
Output Splines6 31 31 31 31
1st Gear Ratio 2.66 2.66 2.97 2.97
2nd Gear Ratio 1.78 1.78 2.10 2.10
3rd Gear Ratio 1.30 1.30 1.46 1.46
4th Gear Ratio 1.00 1.00 1.00 1.00
5th Gear Ratio 0.80 0.74 0.74 0.80
6th Gear Ratio 0.63 0.50 0.50 0.63
Reverse Gear Ratio 2.90 2.90 2.90 2.90
Note * Uses stock ratios for “M6” 1994-2002 Camaro/Firebird. 1993 Camaro/Firebird ratios unavailable.
Note 1 Direct replacement for 1998-2002 Camaro/Firebird with the exception of output spline. See Note 6.
Note 2 Direct fit when installed behind LS1/LS2 with factory T-56 bellhousing. Later engines require pilot bearing change.
Note 3 Performance may vary based on factors such as use, weight, driveline configuration, peripheral parts selection, and quality of the installation.
Note 4 Accepts factory internal slave cylinder from 1998-2002 Camaro/Firebird. Not compatible with 1993-1997 external slave configuration.
Note 5 Same as OEM in 1993-2002 Camaro/Firebird.
Note 6 Require a change of driveshaft slip yoke in 1993-2002 Camaro/Firebird. OEM is 27-spline.
Shifter Location from Rear Face of Block/Front Face of Bellhousing (inch/cm) 29.4 in/74.6 cm
Input Shaft Length from Front Face of Trans (inch/cm) 6.46 in/16.4 cm
Crossmember Mounting Location from Rear
Face of Block/Front Face of Bellhousing (inch/cm)
26.6 in/67.5 cm
Overall Length (inch/cm) 31.8 in/80.9 cm
Crossmember Mounting Location from Mainshaft Centerline (inch/cm) 3.4 in/8.5 cm
Dry Weight 128 lbs.
Shipping Weight 146 lbs.
Fluid capacity (quarts/liters) Approx. 4.0 Qt /3.8 L
Recommended Fluid TREMEC HP-MTF, Dexron-III, or Mobil 1 ATF


Driving Techniques
A 500-mile break-in period will prevent premature wear and possible damage to the transmission. During the
break-in period, you must avoid high RPM shifts and “drag” starts. The clutch must be fully disengaged to shift
the transmission. Do not use excessive force when shifting the transmission. If you experience clash shifts
(grinding), check clutch travel to ensure proper air-gap is achieved. Another possible cause of clash shifting is
improper transmission installation (excessive driveline angle / resulting in poor driveline alignment). Do not hold
the transmission in gear by applying force on the shifter. This will damage the pads on the shift forks and may
result in significant damage to the transmission.
