Quick Time Bellhousing RM-8020PB with fork pivot/ Chevy LS1 to LS1 T56



Bellhousing, QuickTime, W/ fork pivot, Chevy LS-1 to LS1 T56 with a mechanical fork, SFI 6.1

Built from high-grade steel – Work hardens to over 80,000 PSI strength.
Over 2 times the strength of any other steel bellhousing.

Categories: , , SKU: MD-401-8020-Piv


Quick Time Bellhousing RM-8020PB W/ fork pivot, Chevy LS1 to LS1 T56


  • Whatever engine or transmission you have – hard-to-find and even one-of-a-kind applications are a reality with Quick Time
  • Twice the strength of other steel bellhousings, with pinpoint dimensional accuracy and stability that obsoletes lesser models made from rolled or stamped steel
  • The engine and transmission always stay in alignment through the entire rpm range, eliminating accelerated drivetrain wear caused by bellhousing flex
  • Patent Pending on 16 points of Bellhousing Design & Process
  • 100% built in the USA
  • Design input from OEM, Engine Builders, Transmission Builders, Racers, and the Hobbyist
  • Quick Time Bellhousings are the most accurate bellhousings available due to our unique manufacturing process
  • This bell eliminates the need for hydraulics. Uses Chevy Push Style Fork.
Certification 6.1 SFI
Engine GM Small Block Gen III/IV (LS Based)
Flywheel 168 Tooth
Height 5.500 inch
Included Hardware Full Engine Plate and Grade 8 Bolts
Trans Bore N/A
Transmission T56 GM, GM Magnum
Weight 22#


HOW TO: DIal in a T56 bellhousing with an indexing plate Video


Don’t see what you’re looking for, please call  208-453-9800

Additional information

Weight 544 oz
Dimensions 18 × 18 × 8 in
