    MDL, Ford Flathead Adapter to Ford 83-93 Mustang T5 with Round End Clutch Fork Shaft

    Thumbnail Filmstrip of MDL, Ford Flathead Adapter to Ford 83-93 Mustang T5 with Round End Clutch Fork Shaft Images

      Purchase MDL, Ford Flathead Adapter to Ford 83-93 Mustang T5 with Round End Clutch Fork Shaft

      MDL

      MDL, Ford Flathead Adapter to Ford 83-93 Mustang T5 with Round End Clutch Fork Shaft

      SKU: MD-401-2109-T5

      No reviews yet. Write a review!
      $725.00 Original Price
      Price excludes tax

      Bellhousing Adapter Assy. What it Fits: 32-48 Ford V8 Flathead Car, 49 Truck 49-50 Merc Car to 83-93 Ford Tremec T5. What it comes with:
      • Clutch Fork
      • Clutch Cross shaft
      • Mech T/O bearing
      • Ford T-5 trans sizing ring ** Requires our Flathead conversion clutches.

      Key Features

      • Bellhousing alignment pins to maintain.001" Greaseless clutch shaft bushings, and with a self-centering throwout bearing1983-93 Ford T5 mounting pattern is clocked 7 degrees CCW to make the tail shaft housing mount flat.Machined from 6061 Billet Alu

        Prop 65 Warning

      This product may expose you to chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.


      Join Waitlist

      Sign up with your email to be notified when this is back in stock!


      Comes with?

      Clutch fork Clutch cross shaft Mechanical throw-out bearing Ford T5 transmission sizing ring Mounting hardware

      Detailed Design.

      MD-401-2109-T5 is designed to use Front shifted 83-93 Ford V8 T-5 instead a S-10 T-5 with low gearing not well suited for a V8 Flathead. Comed with Updated self-centering, continuous duty release bearing. Release shaft is machined for the early lever type clutch release. If you need later extended shaft release see MD-401-2109S-T-5.

      Special Notes

      If you need the slotted/flat-end shaft, see MD-401-2109S-T5. The 32-52 Flathead to Ford T5 Adapter plate does not fit with S10 T-5 Ford 83-93 Mustang T5 transmission sizing ring.Requires MDL 10" Flathead conversions clutches. ** Requires our Flathead conversion clutches.'.

      If you don't see what you're looking for please call 208-453-9800

      Specifications

      Adapter Trans Model
      83-93 Ford T-5
      Bell Pattern
      Ford Flathead Circular
      Bell Clutch Release Type
      Mechanical
      Transmission
      Front shifted Ford 83-93 T5

      FAQs

      Q. Will this adapter work with a "Ford pattern" S-10 T-5? A. While the bolt pattern is the same the S-10 has a longer input shaft with a smaller bearing retainer od base. Our adapter was not designed for S-10 T-5. S-10 T-5 are geared low and are not ideal for Ford V8 flatheads.
