TREMEC T5 Custom T5 by MDL
Fits: 1994-1995 V8, and 1994-1999 V6 SN95 Mustang/Cobra
With a 7.8in. input shaft and Steel bearing retainer.
The 94-95 SN95 Mustang/Cobra Super Duty T-5z is a step up from the T5s used in the 1994-95 5.0L Mustangs.
The gear sets in the earlier T5s were built with a 3.35 first gear with a .68 overdrive.
The Super Duty T-5z is built with a 2.95 first and a .63 overdrive idea for a 3.55:1 axle ratio as well as more torque handling than its former counterparts.
This transmission is built specifically for the aftermarket and is enhanced by Modern Driveline to fit the SN95 Mustangs.
Can also be used in other cars that are using the 94-95 bellhousing with a seven O'clock fork opening or Fox body bellhousing and MD-401-2110 spacer plate
Product Features:
- Torque rating 330 ft/lbs (conservative rating, Street-car to 450hp OK)
- Gear Ratios 2.95, 1.94, 1.34, 1, .63 OD
- Steel front bearing retainer
- Cobra style pocket bearing
- Carbon fiber 1,2,3,4 synchro rings
- World Class (tapered carrier bearings, main needle bearings)
- 10 spline input shaft
- 28 spline output shaft
- 7 tooth speedo drive gear (Optional 6 or 8-tooth available)
- Optional .73:1 Overdrive ratio available
- Required Oil Type = 2.75 quarts of ATF Dextron III
- 1352-238, 1352-242, 1352-246, 1352-252, 1352-253
- 1994-1995 Ford Mustang/Cobra
- 1994-98 Ford Mustang 3.8L V6
- (Will work with 99-04 with speedo ERA speedometer adapter)
