55-57 Tri-5 Chevy LF Series Hydraulic Clutch Master Kit with integral reservoir

$189.00

-


LF Series Hydraulic
Engineered Solution

55-57 Tri-5 Chevy Hydraulic Clutch Master Kit – Type 2

Categories: , , , SKU: MD-910-0100

Description

1955-57 Tri 5 Chevy, LF Series Hydraulic Clutch Master Kit
Type 2 (.700″ bore x 1.4″ Stroke)

MDL Tri-5 Chevy Master cylinder kit that mounts on the outside of the firewall directly in front of the clutch pedal to provide plenty of motor clearance while not loading the pedal shaft.
The Master cylinder is equipped with integral reservoir for a compact size and clean look.

All MDL Hydraulic kits come with our 1-man Bleeder kit to make installation easier.

Applications:  1955-1957 Tri-5 Chevy

LF (Light Foot) Series

    • Uses stock clutch pedal, reduces the load on the pivot shaft.
    • Master is located directly in front of the clutch pedal.
    • Firewall support plate
    • Works with most internal and external slaves.
    • .750″ bore master also available.

If you are pairing this with any other slaves, give us a call to be sure you are getting the correct sized cylinder for your application.



  Don’t see what you’re looking for, please call  208-453-9800

Additional information

Weight 32 oz
Dimensions 9 × 5 × 3 in

INSTRUCTIONS

IN-910-0100 Rev 5



Bleeder Kit rev 4

SPECS

Dimensions:

Type 2 = .700″ bore x 1.4″ stroke (.539cu/in) This is the preferred size for all of our slave cylinders.
Type 3 = .750″ bore x 1.4″ stroke (.618cu/in)

Output fitting size = AN4
