66-70 Fairlane/Falcon/Comet 68-71 Torino Hydraulic Clutch Master Kit .750″ bore x 1.4″ stroke

$285.00


LF Series Hydraulic
Engineered Solution

66-70 Fairlane Hydraulic Clutch Master Kit – Type 3

Description

1966-70 Fairlane, Falcon/Comet, 68-71 Torino
MDL Hydraulic Clutch Master Kit – Type 3 (.750″ bore x 1.4″ stroke)

From the SEMA award-winning team that brought you the SN95 Mustang Hydraulics.

Modern Driveline’s Lightfoot series Hydraulic Master cylinder clutch cylinder kit uses the stock clutch pedal.
Engineered to use the factory full swing of the pedal, for maximum leverage, it provides a light pedal effort and full control of the clutch, this translates to a drive you will love.

Unique to MDL is the clutch pedal linkage allows the master cylinder to use the stock clutch rod hole while providing room for factory vacuum brake booster but, most importantly driver control.
Gone of the days of having to engineer a kit from scratch only to leave you frustrated with the results.

All MDL Hydraulic kits come with our 1-man Bleeder kit to make installation easier.

The 66-70 Fairlane Hydraulic Clutch Master Kit utilizes a small bore long stroke cylinder to provide the most common fluid volume requirements needed in today’s hydraulic slave cylinders.  Couple this master cylinder kit with either MDL LF series external slave cylinders kit or Tilton Engineering internal hydraulic release bearings results in complete hydraulic clutch solution ready to install.

Applications:

  • 1966-70 Fairlane, Falcon/Comet
  • 1968-71 Torino
  • 1970-79 Maverick
  • 1975-81 Granada

LF (Light Foot) Series

  • Pedal linkage for light pedal effort
  • Uses stock clutch pedal and rod hole (where possible) for ease of installation
  • Included remote reservoir
  • Works with most internal and external slaves.

Common Hydraulic Conversion Problems

The common approach was to use a 3/4″ or 7/8″ bore x 1″ stroke master cylinder connected to the pedal directly resulting in the following.

  • Improper pedal pressure and stroke the cylinder needed to be raised higher than the stock clutch rod linkage hole.
  • Interference issues on the firewall or pedal assembly.
  • Heavy pedal pressure or a very short stroke or both.

Revolutionary Linkage Design

The LF Series Hydraulic Clutch Master is a revolutionary design for retrofitting hydraulics into the classic cars

Modern Driveline solved these issues with innovative pedal linkage that matches pedal travel with a long stroke master cylinder for a reduced clutch pedal load.  The linkage allows for great design flexibility and greatly improved driver’s experience. We offer the master cylinders in three different bore sizes to match the slave cylinder volume requirements.  In most cases, our .700″ bore with 1.4″ stroke is the perfect match for most slave cylinders on the market and all our LF series slaves, Tilton 6000 Series internal bearings.

Click here to learn more about the Tilton 6000 Slave Throw-out bearing

Please contact us if you have any special requirements.   208-453-9800

  • The long-stroke, small bore master cylinder provides minimize loading of the firewall and pedal effort.
  • A firewall plate with mechanical linkage greatly reduces firewall load and pedal effort while providing design flexibility to use the stock clutch rod hole.
  • The mechanical linkage design also allows the full stroke of the pedal to maximize clutch modulation while keeping the cylinder perpendicular to the firewall and provide mechanical advantage thus reducing the pedal pressure required to operate the clutch.

Complete Solutions

Complete solutions of master and slave need to be optimized with matching fluid volume.
For this reason, we offer kits specifically matched to our slaves or to existing slaves on the market. See our recommended slave cylinders below.

Every LF series hydraulic master kit comes with a one-man bleeder kit

  Don’t see what you’re looking for, please call  208-453-9800

Additional information

Weight 32 oz
Dimensions 9 × 5 × 3 in

INSTRUCTIONS

Every LF series hydraulic master kit comes with a one-man bleeder kit

    Bleeder kit instructions

SPECS

Dimensions:

Type 2 = .700″ bore x 1.4″ stroke (.539cu/in) This is the preferred size for all of our slave cylinders.
Type 3 = .750″ bore x 1.4″ stroke (.618cu/in)

Output fitting size = AN4

The brake booster below due to its profile & mounted distance from the firewall will allow the Hydraulic Master to be mounted correctly.
